Lexmark C4150 User Manual

Action Yes No
Step 6
Check the cable for damage, and replace if necessary.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
Replace the control panel cable.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
Replace the control panel. See
“Upper control panel removal” on
page 280.
Does the problem remain?
Go to step 12. The problem is
solved.
Step 9
Disconnect the LVPS cable from the controller board, and then
measure the voltages of the red and orange wires.
Is the reading on the red wire +6.5 V, and the orange wire +25 V?
Go to step 12. Go to step 10.
Step 10
Replace the LVPS cable.
Does the problem remain?
Go to step 11. The problem is
solved.
Step 11
Replace the LVPS. See
“LVPS removal” on page 305.
Does the problem remain?
Go to step 12. The problem is
solved.
Step 12
Replace the controller board. See
“Controller board removal” on
page 357.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
Interlock switch service check
Action Yes No
Step 1
a Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Sensor tests
b Find the sensor (Door interlock).
Does the sensor status change while toggling the sensor?
The problem is
solved.
Go to step 2.
5028
Diagnostic information
224

Lexmark C4150 Specifications

General

Drivers included	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Time to first page (color, normal)	5.5 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C6, DL
Paper tray media types	Plain paper, Recycled paper, Thin paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Wi-Fi	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Maximum internal memory	3072 MB
Sound pressure level (printing)	53 dB
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Power consumption (printing)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Depth	497.84 mm
Width	474.98 mm
Height	416.56 mm
