4 Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Color alignment adjust
On the AA Adjustment row, touch Start.
The Color alignment procedure is performed on the cyan, magenta, and yellow colors.
Note: The procedure may not work for old
firmware
versions. Make sure that the latest
firmware
version
is installed.
5 Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Color alignment adjust > Cyan > Quick test
Check the alignment markings on the test page generated. Follow the instructions on the test page to correct
the color misalignment.
6 Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Color alignment adjust > Yellow > Quick test
Check the alignment markings on the test page generated. Follow the instructions on the test page to correct
the color misalignment.
7 Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Color alignment adjust > Magenta > Quick test
Check the alignment markings on the test page generated. Follow the instructions on the test page to correct
the color misalignment.
8 If color misalignment still occurs, then repeat steps 4 to 7.
Removal procedures
Keep the following tips in mind as you replace parts:
• Some removal procedures require removing cable ties. You must replace cable ties during reassembly to
avoid pinching wires, obstructing the paper path, or restricting mechanical movement.
• Remove the toner cartridges, imaging unit, and media tray before removing other printer parts. The imaging
unit should be carefully set on a clean, smooth, and flat surface. It should also be protected from light while
out of the device.
• Disconnect all external cables from the printer to prevent possible damage during service.
• Unless otherwise stated, reinstall the parts in reverse order of removal.
• When reinstalling a part held with several screws, start all screws before the
final
tightening.
Cover removals
Front cover removal
1 Open the front door, and then disconnect the two straps (A).
CAUTION—POTENTIAL INJURY: Make sure that the front door has support after the straps are
removed to avoid damage.
5028
Repair information
265

Lexmark C4150 Specifications

General

Drivers included	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Time to first page (color, normal)	5.5 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C6, DL
Paper tray media types	Plain paper, Recycled paper, Thin paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Wi-Fi	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Maximum internal memory	3072 MB
Sound pressure level (printing)	53 dB
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Power consumption (printing)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Depth	497.84 mm
Width	474.98 mm
Height	416.56 mm
