Lexmark C4150 User Manual

System software error service check
There are
dierent
types of 900.xx errors that can occur. There may be a communication problem (bad
cable, network connection, and so on) software issue, or a hardware problem with the controller board, or
ISP (internal solutions port). The communication and software aspects should be checked first. Determine
if the problem is constant or intermittent. Use the following troubleshooting procedure to isolate the issue.
Take notes as instructed. You will need that information in the event that you need to contact your next level
of support.
Before troubleshooting:
1 Perform the “Procedure before starting the 9yy service checks” on page 207.
2 Determine the operating system used when the error occurred. If possible, determine whether a
PostScript or PCL file was sent to the printer when the error occurred. Ask the customer which Lexmark
Solutions applications are installed on the printer.
Action Yes No
Step 1
Reset the printer.
Does the error remain?
Go to step 2. The problem is
solved.
Step 2
a Write down the exact 900.xx error code that appears on the
display.
b Turn o the printer.
c Clear the print queues.
d Disconnect all communication cables, and then remove all
memory options.
e Remove any installed ISP.
f Reset the printer into the Diagnostics menu.
Does the problem remain?
Go to step 3. Go to step 6.
Step 3
Check all the cables on the controller board for proper connection.
Are the cables properly connected?
Go to step 5. Go to step 4.
Step 4
a Reconnect the cables.
b Reset the printer into the Diagnostics menu.
Does the problem remain?
Go to step 5. Go to step 6.
5028
Diagnostic information
213

Lexmark C4150 Specifications

General

Drivers included	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Time to first page (color, normal)	5.5 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C6, DL
Paper tray media types	Plain paper, Recycled paper, Thin paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Wi-Fi	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Maximum internal memory	3072 MB
Sound pressure level (printing)	53 dB
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Power consumption (printing)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Depth	497.84 mm
Width	474.98 mm
Height	416.56 mm
