Lexmark C4150 User Manual

Action Yes No
Step 5
• If the aected color is cyan, magenta, or yellow, then replace
the developer unit of the
aected
color.
• If the aected color is black, then replace the imaging unit.
Does the problem remain?
Go to step 6. The problem is
solved.
Step 6
a Remove the imaging kit.
b Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Motor tests
c Select the developer unit motor of the
aected
color, and then
touch Start.
Does the motor run?
Go to step 8. Go to step 7.
Step 7
Replace the motor. See
“Motor (EP drive) removal” on page
296.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
a Manually turn the motor.
b While turning the motor, check if the couplers that drive the
imaging kit move.
Do the couplers move?
Go to step 10. Go to step 9.
Step 9
Replace the EP gear box. See
“EP gear box removal” on
page 302.
Does the problem remain?
Go to step 10. The problem is
solved.
Step 10
Check if the pins on the HVPS freely move.
Do the pins freely move?
Go to step 12. Go to step 11.
Step 11
Replace the HVPS. See
“HVPS removal” on page 319.
Does the problem remain?
Go to step 12. The problem is
solved.
Step 12
Check the continuity of the cable on the JSC1 connector on the
controller board.
Does the cable have continuity?
Go to step 14. Go to step 13.
5028
Diagnostic information
38

Lexmark C4150 Specifications

General

Drivers included	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Time to first page (color, normal)	5.5 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C6, DL
Paper tray media types	Plain paper, Recycled paper, Thin paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Wi-Fi	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Maximum internal memory	3072 MB
Sound pressure level (printing)	53 dB
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Power consumption (printing)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Depth	497.84 mm
Width	474.98 mm
Height	416.56 mm
