Connector Connects to Pin no. Signal
JMTR1 Isolation unit motor and pick motor and
sensors
1VS10_BA_LED
2V30_BA+
3S_BA_ENC
4V30_BA-
5GND
6GND
7VS10_ISO_LED
8V30_ISO-
9S_ISO_ENC
10 V30_ISO+
11 VS10_MPF_LED
12 S_MPF_ENC
13 GND
14 V40_MPF+D
15 V40_MPF-M
16 VS10_PE_LED
17 S_PE_ENC
18 GND
19 V40_PE-M
20 V40_PE+D
21 VS10_ELEV
22 S_ELEV_IN
23 GND
24 VS10_EMP
25 S_T1_EMP
26 GND
JTHM1 Thermistor 1 S_TT_IN
2GND
5028
Component locations
395
