Lexmark MX317 - Component Locations; Exterior Locations; Front View

Component locations
Exterior locations
Front view
Printer configurations
CAUTION—TIPPING HAZARD: Floor‑mounted
configurations
require additional furniture for stability.
You must use either a printer stand or printer base if you are using a high‑capacity tray and an input
option, or more than one input option. If you purchased a multifunction printer (MFP) that scans, copies,
and faxes, you may need additional furniture. For more information, see
www.lexmark.com/multifunctionprinters.
You can configure your printer by adding an optional 250‑ or 550‑sheet tray.
1
2
3
4
9
10
6
5
8
7
1 Printer control panel
2 Automatic document feeder (ADF)
3 ADF tray
4 ADF bin
7015
Component locations
409
