Lexmark OPTRA 4069-XXX User Manual

Diagnostic Aids 3-23
4069-XXX
Print Contrast
The print contrast setting controls the developer voltage offset.
The print contrast can be adjusted as follows:
• LOW
• MEDIUM
• HIGH
Charge Roll
The charge roll can be adjusted as follows:
• LOW
• MEDIUM
• HIGH
Print Tests
The purpose of the diagnostic Print Tests is to verify that the printer
can print on media from each of the installed input options. Each of
the installed options is listed in the following order in the menu:
Tray 1
Tray 2 (if installed)
Tray 3 (if installed)
Tray 4 (if installed)
Tray 5 (if installed)
Multipurpose Feeder (if installed)
Envelope Feeder (if installed)
For each input source selected you have the following choice:
• Single (prints the Print Test Page once)
• Continuous (continue printing the Print Test Page until Return or
Stop is pressed).
