5-22 Service Manual
4069-XXX
High-Capacity Output Stacker Board
Connector Pin No. Signal
J1A Autoconnect 1 +24 V dc
2 Ground
3 +5 V dc
J1B 1 Prtxdin
2 Ground
3prtrxd
4 Ground
5N/C
J2A Autoconnect 1 +24 V dc
2 Ground
3 +5 V dc
J2B 1 prtxdout
2 Ground
3prtrxd
4 Ground
J3 Pass Thru Sensor 1 Ground
2 Paper Present
3RVsnsr
J4 DC Motor 1 mtrout1
2 mtrout2
3 Ground
4 Ground
5 tach +
6 +5 V dc
