Lexmark S415 User Manual

How can I make sure my computer and printer are connected to the same
wireless network?
If the printer is not on the same wireless network as the computer, then you will not be able to print wirelessly. The
SSID of the printer must match the SSID of the computer, if the computer is already connected to the wireless network.
For Windows users
1 Obtain the SSID of the network that the computer is connected to:
a Type the IP address of your access point (wireless router) in the address field of your Web browser.
If you do not know the IP address of the access point:
1 Click , or click Start and then click Run.
2 In the Start Search or Run box, type cmd.
3 Press Enter, or click OK.
4 Type ipconfig, and then press Enter. Check the Wireless Network Connection section:
• The “Default Gateway” entry is typically the access point.
• The IP address appears as four sets of numbers separated by periods, such as 192.168.2.134.
b Type the user name and password of the router when prompted.
c Click OK.
d In the Wireless settings section, look for the SSID.
e Write down the SSID.
Note: Make sure you copy it exactly, including any capital letters.
2 Obtain the SSID of the network that the printer is connected to:
a From the printer, print a network setup page.
b In the Wireless section, look for SSID.
3 Compare the SSID of the computer and SSID of the printer.
If the SSIDs are the same, then the computer and the printer are connected to the same wireless network.
If the SSIDs are not the same, then run the utility again to set up the printer on the wireless network used by the
computer.
For Macintosh users with an AirPort base station
In Mac OS X version 10.5 or later
1 From the Apple menu, navigate to:
System Preferences > Network > AirPort
The SSID of the network that the computer is connected to is displayed in the Network Name menu.
2 Write down the SSID.
Networking 112

Lexmark S415 Specifications

General

Display	LCD
Modem speed	33.6 Kbit/s
Color faxing	Yes
Network ready	No
Dimensions (WxDxH)	432 x 366 x 268 mm
All-in-one functions	Copy, Fax, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	copy, fax, print, scan
Compatible operating systems	Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 x64 Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows 7 Microsoft Windows 7 x64 Microsoft Windows Server 2008 R2
Print technology	Inkjet
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	30 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	7000 pages per month
Maximum copy resolution	- DPI
Copy speed (black, normal quality, A4)	25 cpm
Copy speed (color, normal quality, A4)	21 cpm
Scanner type	ADF scanner
Maximum scan area	216 x 356 mm
Optical scanning resolution	1200 x 1200 DPI
Total input capacity	100 sheets
Total output capacity	25 sheets
Envelopes sizes	6 3/4, B5, C6, DL
Maximum print size	-
Paper tray media types	Banner, Card stock, Envelopes, Iron-On Transfers, Plain paper, Transparencies
Non-ISO print media sizes	2L, L
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Display diagonal	2.4 \
Market positioning	Home & office
Standard interfaces	USB 2.0, Wireless LAN
Wi-Fi standards	802.11b, 802.11g
Processor frequency	330 MHz
Sound power level (standby)	16 dB
Sound pressure level (copying)	48 dB
Sound pressure level (printing)	46 dB
Sound pressure level (scanning)	45 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (average operating)	32 W
Package weight	10270 g
Sustainability certificates	ENERGY STAR
Certification	Energy Star, CSA, c-UL-us, ICES Class B, Executive Order 132221, CE Class B, CB IEC 60950 IEC 60825-1, GS (TÜV), SEMKO, C-tick mark Class B, V85, CCC Class B, BSMI Class B, METI(PSE), VCCI Class B, FCC Class B, UL 60950 3rd Edition, CCIB
Keyboard layout	AZERTY
Pointing device	Clickpad
Recovery operating system	Windows 10
Operating system architecture	32-bit
Optional operating system supplied	Windows 10 Education
Optional operating system installed	Android 5.1
Scalability	1S
Intel® Turbo Boost Technology	1.0
Thermal solution specification	PCG 2011A
Intel Virtualization Technology for Connectivity (VT-c)	0
Cable lock slot type	IBM
Docking station power connector	24-pin
Docking station graphics card model	AMD Radeon HD R9 290
Docking station connecting interface	Lenovo OneLink
Docking station audio output channels	2.0
Docking station graphics card memory type	GDDR5
Docking station graphics card manufacturer	PNY
