RECONNECT THE PRINTER POWER SUPPLY
1 Turn off the printer.
Note: Make sure the printer is not in Sleep mode. Press and hold
for three seconds to turn off the printer.
2 Unplug the power cord from the wall outlet, and then pull out the power cord from the power supply.
3 After one minute, reconnect the power cord into the power supply, and then plug the power cord into the wall
outlet.
4 Turn on the printer.
RUN THE INSTALLER AGAIN
1 Close the installer.
2 Remove the CD, and then restart the computer.
3 Insert the CD, and then run the installer again.
MAKE SURE YOUR COMPUTER IS ABLE TO ACKNOWLEDGE USB ACTIVITY ON THE USB PORT
Open the Device Manager to check if it has activity whenever a USB device is connected to a USB port:
1 Click , or click Start and then click Run.
2 In the Start Search or Run box, type devmgmt.msc.
3 Press Enter, or click OK.
4 Watch the Device Manager window while connecting a USB cable or another device to the USB port. The window
refreshes when the Device Manager recognizes the USB connection.
• If there is activity on the Device Manager but none of the previous solutions worked, then call customer
support.
• If there is no activity on the Device Manager, then there may be a problem with your computer and its USB
support. The computer must recognize the USB connection in order for installation to work.
Cannot print and there is a firewall on the computer
Third‑party (non‑Microsoft) firewalls can interfere with wireless printing. If the printer and computer are configured
correctly, and the wireless network is working, but the printer will not print wirelessly, then a firewall could be the
problem. If there is a firewall (other than the Windows firewall) on the computer, try one or more of the following:
• Update the firewall using the most recent update available from the manufacturer. Refer to the documentation
that came with your firewall for instructions on how to do this.
• If programs request firewall access when you install the printer or try to print, make sure you allow those programs
to run.
• Temporarily disable the firewall and install the wireless printer on the computer. Re‑enable the firewall when you
have completed the wireless installation.
Troubleshooting 152

Lexmark S415 Specifications

General

Display	LCD
Modem speed	33.6 Kbit/s
Color faxing	Yes
Network ready	No
Dimensions (WxDxH)	432 x 366 x 268 mm
All-in-one functions	Copy, Fax, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	copy, fax, print, scan
Compatible operating systems	Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 x64 Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows 7 Microsoft Windows 7 x64 Microsoft Windows Server 2008 R2
Print technology	Inkjet
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	30 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	7000 pages per month
Maximum copy resolution	- DPI
Copy speed (black, normal quality, A4)	25 cpm
Copy speed (color, normal quality, A4)	21 cpm
Scanner type	ADF scanner
Maximum scan area	216 x 356 mm
Optical scanning resolution	1200 x 1200 DPI
Total input capacity	100 sheets
Total output capacity	25 sheets
Envelopes sizes	6 3/4, B5, C6, DL
Maximum print size	-
Paper tray media types	Banner, Card stock, Envelopes, Iron-On Transfers, Plain paper, Transparencies
Non-ISO print media sizes	2L, L
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Display diagonal	2.4 \
Market positioning	Home & office
Standard interfaces	USB 2.0, Wireless LAN
Wi-Fi standards	802.11b, 802.11g
Processor frequency	330 MHz
Sound power level (standby)	16 dB
Sound pressure level (copying)	48 dB
Sound pressure level (printing)	46 dB
Sound pressure level (scanning)	45 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (average operating)	32 W
Package weight	10270 g
Sustainability certificates	ENERGY STAR
Certification	Energy Star, CSA, c-UL-us, ICES Class B, Executive Order 132221, CE Class B, CB IEC 60950 IEC 60825-1, GS (TÜV), SEMKO, C-tick mark Class B, V85, CCC Class B, BSMI Class B, METI(PSE), VCCI Class B, FCC Class B, UL 60950 3rd Edition, CCIB
