Lexmark S415 User Manual

If the printer is currently set up for wireless
1 Attach a USB cable to the computer and to the printer.
2 Wait a moment for Windows to locate the driver and finish setting up the printer.
3 Select the USB printer. See “Selecting the printer” on page 99.
Note: You can continue to use the printer through Ethernet or wireless connection.
Using the printer over an Ethernet network
Select the connection type that describes how you currently access your printer:
If the printer is currently set up for wireless
1 Plug an Ethernet cable into the printer and into an available port on a switch or wall jack.
2 Wait one minute for the Ethernet network adapter to become active and acquire an IP address from the network.
3 Select the Network printer. See “Selecting the printer” on page 99.
Note: The wireless adapter of the printer is disabled while it is connected to an Ethernet network.
If the printer is currently set up locally (using USB connection)
1 Plug an Ethernet cable into the printer and into an available port on a switch or wall jack.
2 Insert the installation software CD into the computer you want to use to configure the printer.
3 Follow the instructions on the computer screen for configuring a printer on an Ethernet network.
4 Select the Network printer. See “Selecting the printer” on page 99.
Note: You will need a USB cable to complete the configuration.
Selecting the printer
1 Open the printers folder.
a Click or Start.
b In the Start Search or Run box, type control printers.
c Press Enter, or click OK.
2 Right‑click the printer you want to use (Network or USB).
3 Select Set as Default Printer from the menu.
4 Close the “Printers” or “Printers and Faxes” window.
Switching between USB, Ethernet, and wireless connections (Macintosh only)
You can change the way you access your printer depending on your needs. The following procedures assume that you
have configured your printer for one type of connection and that the drivers are installed on the computer. See related
topics on troubleshooting specific connection types if you encounter difficulties during configuration.
Note: The printer supports one active local connection (USB) and one active network connection (Ethernet or
wireless) at a time. It is not possible to connect the printer to both Ethernet and wireless networks at the same time.
Networking 99

Lexmark S415 Specifications

General

Display	LCD
Modem speed	33.6 Kbit/s
Color faxing	Yes
Network ready	No
Dimensions (WxDxH)	432 x 366 x 268 mm
All-in-one functions	Copy, Fax, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	copy, fax, print, scan
Compatible operating systems	Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 x64 Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows 7 Microsoft Windows 7 x64 Microsoft Windows Server 2008 R2
Print technology	Inkjet
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	30 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	7000 pages per month
Maximum copy resolution	- DPI
Copy speed (black, normal quality, A4)	25 cpm
Copy speed (color, normal quality, A4)	21 cpm
Scanner type	ADF scanner
Maximum scan area	216 x 356 mm
Optical scanning resolution	1200 x 1200 DPI
Total input capacity	100 sheets
Total output capacity	25 sheets
Envelopes sizes	6 3/4, B5, C6, DL
Maximum print size	-
Paper tray media types	Banner, Card stock, Envelopes, Iron-On Transfers, Plain paper, Transparencies
Non-ISO print media sizes	2L, L
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Display diagonal	2.4 \
Market positioning	Home & office
Standard interfaces	USB 2.0, Wireless LAN
Wi-Fi standards	802.11b, 802.11g
Processor frequency	330 MHz
Sound power level (standby)	16 dB
Sound pressure level (copying)	48 dB
Sound pressure level (printing)	46 dB
Sound pressure level (scanning)	45 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (average operating)	32 W
Package weight	10270 g
Sustainability certificates	ENERGY STAR
Certification	Energy Star, CSA, c-UL-us, ICES Class B, Executive Order 132221, CE Class B, CB IEC 60950 IEC 60825-1, GS (TÜV), SEMKO, C-tick mark Class B, V85, CCC Class B, BSMI Class B, METI(PSE), VCCI Class B, FCC Class B, UL 60950 3rd Edition, CCIB
