Equipment and service options Fax connection setup
Connect directly to the telephone line See “Connecting to an analog telephone line” on
page 84
Connect to a Digital Subscriber Line (DSL or ADSL) service See “Connecting to a DSL service” on page 84.
Connect to a Private Branch eXchange (PBX) or Integrated
Services Digital Network (ISDN) system
See “Connecting to a PBX or ISDN system” on page 85.
Use a Distinctive Ring service See “Connecting to a distinctive ring service” on page 85.
Connect to a telephone line, telephone, and answering
machine
See “Connecting the printer and a telephone or answering
machine to the same telephone line” on page 86
Connect through an adapter used in your area See “Connecting to an adapter for your country or region”
on page 87.
Connect to a computer with a modem See “Connecting to a computer with a modem” on
page 91.
Connecting to an analog telephone line
If your telecommunications equipment uses a US-style (RJ11) telephone line, then follow these steps to connect the
equipment:
1 Connect one end of the telephone cable that came with the printer to the printer LINE port .
2 Connect the other end of the telephone cable to an active analog telephone wall jack.
Connecting to a DSL service
If you subscribe to a DSL service, then contact the DSL provider to obtain a DSL filter and telephone cord, and then
follow these steps to connect the equipment:
1 Connect one end of the telephone cable that came with the printer to the printer LINE port .
2 Connect the other end of the telephone cable to the DSL filter.
Note: Your DSL filter may look different than the one in the illustration.
Faxing
84
