Lexmark X466 Service Manual

Parts Catalog 7-9
7014-xxx
Assembly 4: Electronics 2
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
4-1 40X5829 1 1 Controller board
2 40X5816 1 1 LSU hsync extension cable
3 40X5832 1 2 Stairway cable
4 40X5833 1 1 Controller board cable
5 40X5344 1 1 Fuser assembly, 115 V
5 40X5345 1 1 Fuser assembly, 230 V
5 40X5346 1 1 Fuser assembly, 100 V
6 40X5365 1 1 Duplex and media sensor assembly
7 40X5360 1 1 Access door open sensor assembly
8 40X5392 1 1 Cooling fan (screws included)
9 40X5830 1 1 Engine board,
10 40X5385 1 1 Toner low sensor
11 40X5842 1 1 LVPS/HVPS card assembly, 110 V
11 40X5841 1 1 LVPS/HVPS card assembly, 220 V
12 40X5366 1 1 Manual input sensor assembly
13 40X5369 1 1 Manual feed solenoid
14 40X5371 1 1 MPF feed clutch
15 40X5370 1 1 Media feed (ACM) clutch
16 40X5387 1 1 LSU, (printhead)
17 40X5805 1 1 Controller board fan
NS 40X5817 1 1 LSU laser diode cable

Lexmark X466 Specifications

General

Print Resolution	1200 x 1200 dpi
Processor Speed	400 MHz
Fax Speed	33.6 Kbps
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac, Linux
Print Technology	Laser
Duplex Printing	Yes
Connectivity	USB, Ethernet
Paper Handling	250-sheet input tray, 50-sheet multipurpose tray
Scanner Type	Flatbed, ADF
Scan Resolution	1200 x 1200 dpi
Type	Multifunction
Paper Capacity	300 sheets
Maximum Paper Size	8.5 x 14 inches
