5 Insert the plug of the fax card interface cable into the receptacle of the system board.

6 Replace the system board cover and close the system board door.

Attaching cables

Connect the printer to the computer using a USB cable or Ethernet cable.

Be sure to match the following:

• The USB symbol on the cable with the USB symbol on the printer

• The appropriate Ethernet cable to the Ethernet port

Additional printer setup
