Lexmark X658DE - Page 102

2-68 Service Manual
7462
Go Back
Previous
Next
28x.42
x = bin
number
Right tamper does not
leave home position
failure
Applies to:
StapleSmart finisher
The sensor (right tamper HP)
does not detect that the tamper
has moved from home position.
1. Check all the connections on
the output option controller
card.
2. Check the tamper drive belt
for damage and replace if
needed.
3. Replace the right tamper
motor assembly.
Go to “MFP stapler assembly
tamper drive motor
assembly removal” on
page 4-205.
4. Replace the sensor (tamper
HP).
Go to “MFP stapler assembly
sensor (tamper HP left and
right) removal” on
page 4-213.
4. Replace the output option if
problem remains.
28x.43
x = bin
number
Right tamper does not
move to home
position failure.
Applies to:
StapleSmart finisher
The sensor (right tamper HP)
does not detect that the tamper
has reached home position.
1. Check all the connections on
the output option controller
card.
2. Check the tamper drive belt
for damage and replace if
needed.
3. Replace the right tamper
motor assembly.
Go to “MFP stapler assembly
tamper drive motor
assembly removal” on
page 4-205.
4. Replace the sensor (tamper
HP).
Go to “MFP stapler assembly
sensor (tamper HP left and
right) removal” on
page 4-213.
4. Replace the output option if
problem remains.
28x.44
x = bin
number
Eject home position
jam
Applies to:
StapleSmart finisher
The sensor (eject HP) does not
detect that the eject
mechanism is operating.
1. Check all the connections on
the output option controller
card.
2. Replace the output option if
problem remains.
28x.45
x = bin
number
Eject home position
jam
Applies to:
StapleSmart finisher
The sensor (eject HP) does not
detect the home position upon
completion of normal media
eject operation.
1. Check all the connections on
the output option controller
card.
2. Replace the output option if
problem remains.
Error
code or
message
Error contents Description/Action Possible repair actions
