Parts catalog 7-41
7462
Go Back
Previous
Next
Assembly 20: MFP stapler assembly #2
Asm-
Index
Part
number
Units/
option
Units/ kit
or pkg
Description
1 40X4612 1 1 Handle cover
2 40X4613 1 1 Rear door assembly
3 40X4730 1 1 Stapler cover
4 40X4764 1 1 Hollow cover
5 40X4610 1 1 Right cover
6 40X5544 1 1 Sensor (bin full receive)
7 40X4617 1 2 Finisher bin spring
8 40X5545 1 1 Standard output bin LED
9 40X5727 1 1 LED clear lens
10 40X5720 1 1 LED sensor cover
11 40X4618 1 1 Sensor (finisher bin media present)
12 40X4619 1 1 Media output bin extension
13 40X5541 1 1 Media output bin
14 40X4626 1 1 Sensor (bin full send)
15 40X4625 1 1 Stapler/stacker controller card assembly
16 40X5751 1 1 Attach roller
17 40X4609 1 1 Left cover
18 40X4611 1 1 Top cover
19 40X5906 1 1 Sensor (stapler/stacker pass through)
