Parts catalog 7-43

7462

Go Back

Assembly 21: MFP stapler assembly #3

Asm-

Index

Part

number

Units/

option

Units/ kit

or pkg

Description

1 40X4645 1 1 Media stack flap actuator

2 40X4646 1 1 Media stack flap

3 40X4369 1 1 Sensor (media stack)

4 40X4621 1 1 Left tamper motor assembly

5 40X4622 1 1 Right tamper motor assembly

6 40X4624 1 2 Tamper recoil spring

7 40X4369 1 1 Sensor (tamper HP right)

8 40X4369 1 1 Sensor (tamper HP left)

9 40X4623 1 1 Tamper drive belt

10 40X4369 1 1 Sensor (paddle HP)

11 40X4615 1 1 Paddle drive motor
