Parts catalog 7-57
7462
Assembly 28: MFP 4-bin mailbox assembly #3
Asm-
Index
Part
number
Units/
option
Units/ kit
or pkg
Description
1 40X5750 4 1 Spring
2 40X5728 2 1 Sensor (pass through)
3 40X4635 3 1 Deflector gate solenoid
4 40X5751 1 1 Attach roller
5 40X5545 1 1 Standard output bin LED
6 40X5727 1 1 LED clear lens
7 40X4647 1 1 Output bin LED bracket
8 40X4136 4 1 Media bin full actuator
9 40X4633 4 1 Sensor (media bin full)
10 40X4643 1 1 Transport solenoid
11 40X4634 1 1 4 bin mailbox controller card assembly
12 40X4138 4 1 Media bin deflector
