Lexmark XM1140 - Display removal (MX410, MX51 x)

2 Remove the control panel cover.
Display removal (MX410, MX51x)
1 Remove the control panel assembly. See “Control panel assembly removal” on page 315.
2 Remove the UICC. See “UICC removal” on page 318.
3 Remove the four screws (A) securing the bracket to the keypad assembly.
A
7015
Parts removal
322
