Starting charging
1 Prepare the AC charging cable.
2 Insert the AC charging cable into the outlet of the external power source.
Make sure to hold the body of the plug and insert it firmly into the outlet.
If you have a remote switch, turn it on.
Check that the power indicator on the CCID (Charging Circuit Interrupting Device) is
illuminated.
In order to reduce the load on the electrical socket and plug, when inserting the plug,
use a string, etc., to hang the CCID (Charging Circuit Interrupting Device) on a hook
or equivalent.
The CCID (Charging Circuit Interrupting Device) can be hung by using the hole in the
back. Do not attach the CCID (Charging Circuit Interrupting Device) to the wall with
screws.
3 Unlock the doors and push the charging port
lid to open it.
The AC charging inlet light will illuminate.
1-3. Charging with the plug-in hybrid system
86
