4 Remove the AC charging inlet cap and secure it into the holder on the
charging port lid.
5 Remove the AC charging connector cap and secure it to the cable.
6 Make sure to hold the body of the charging connector and insert it firmly and
fully into the AC charging inlet.
When connecting the charging connector into the AC charging inlet, make sure that
the identification symbols are the same.
When the charging connector is inserted straight as far as possible, it will automatically
lock. Check that the charging indicator illuminates. If the charging indicator does not
illuminate,the charging connector is not locked.
*10
*10 :
If the charging connector is not firmly inserted, locking operation will be performed
several times.
1-3. Charging with the plug-in hybrid system
87
1
Before driving
