LG 27UD69-W User Manual

13
ENGLISH
Installing the wall mount plate
This monitor supports the specification of the standard
wall mount plate or compatible device.
1
Place the screen face down. To protect the screen
from scratches, cover the surface with a soft cloth.
2
Detaching the Stand Body.
3
Place the wall mount plate onto the monitor and
align it with the screw holes.
4
Tighten the four screws to fix the plate to the
monitor using a screwdriver.
y
The wall mount plate is sold separately.
y
For more information on installation, refer to the
wall mount plate's installation guide.
y
Be careful not to use excessive force when
mounting the wall mount plate, as this can dam-
age the monitor's screen.
NOTE
y
Use of the Kensington lock is optional. The acces-
sories can be purchased at your local electronics
store.
NOTE
Using the Kensington lock
The Kensington security system connector is located at
the back of the Monitor set.
For more information on installation and usage, refer to
the Kensington lock user manual or visit the website at
http://www.kensington.com.
Connect the Kensington security system cable between
the Monitor set and a table.

LG 27UD69-W Specifications

General

3D	No
DDC/CI	Yes
Panel type	TFT
Pixel pitch	0.1557 x 0.1557 mm
Screen shape	Flat
Backlight type	W-LED
Display diagonal	27 \
Display technology	LCD
Native aspect ratio	16:9
Peak luminance ratio	90 %
Viewable size, vertical	336.22 mm
sRGB coverage (typical)	99 %
Display number of colors	1.073 billion colors
Viewable size, horizontal	597.73 mm
Digital vertical frequency	56 - 61 Hz
Digital horizontal frequency	30 - 135 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3840 x 2160
On/off switch	-
Headphone outputs	1
VGA (D-Sub) ports quantity	0
Product color	White
Market positioning	Gaming
Tilt angle range	-2 - 15 °
Cable lock slot type	Kensington
Cables included	AC, DisplayPort, HDMI
Package depth	145 mm
Package width	693 mm
Package height	439 mm
Package weight	6400 g
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	47 kWh
Power consumption (standby)	0.3 W
Power consumption (typical)	32 W

Weight and Dimensions

Depth (with stand)	186.2 mm
Height (with stand)	455.7 mm
Weight (with stand)	4900 g
Depth (without stand)	49.3 mm
Width (without stand)	615 mm
Height (without stand)	365.1 mm
Weight (without stand)	4600 g
