LG 27UD69-W User Manual

9
ENGLISH
Installing the Monitor
Assembling the stand base
y
To protect the screen from scratches, cover the
surface with a soft cloth.
CAUTION
1
Place the screen face down.
3
2
Check the direction of the stand body (front, back)
and then mount the stand body onto the stand
hinge.
Stand Body
Stand Body
Stand Base
Screw Cover
Attach the Stand Base to Stand Body.
Tighten the screw to the right.
1
2
4
Attach the screw cover.
Applying excessive force when tightening the
screws may cause damage to the monitor. Dam-
age caused in this way will not be covered by the
product warranty.
CAUTION
To avoid injury to your fingers or feet when you
Assembly the Stand Body and Base, you should
hold the Stand Base firmly.
WARNING

LG 27UD69-W Specifications

General

3D	No
DDC/CI	Yes
Panel type	TFT
Pixel pitch	0.1557 x 0.1557 mm
Screen shape	Flat
Backlight type	W-LED
Display diagonal	27 \
Display technology	LCD
Native aspect ratio	16:9
Peak luminance ratio	90 %
Viewable size, vertical	336.22 mm
sRGB coverage (typical)	99 %
Display number of colors	1.073 billion colors
Viewable size, horizontal	597.73 mm
Digital vertical frequency	56 - 61 Hz
Digital horizontal frequency	30 - 135 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3840 x 2160
On/off switch	-
Headphone outputs	1
VGA (D-Sub) ports quantity	0
Product color	White
Market positioning	Gaming
Tilt angle range	-2 - 15 °
Cable lock slot type	Kensington
Cables included	AC, DisplayPort, HDMI
Package depth	145 mm
Package width	693 mm
Package height	439 mm
Package weight	6400 g
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	47 kWh
Power consumption (standby)	0.3 W
Power consumption (typical)	32 W

Weight and Dimensions

Depth (with stand)	186.2 mm
Height (with stand)	455.7 mm
Weight (with stand)	4900 g
Depth (without stand)	49.3 mm
Width (without stand)	615 mm
Height (without stand)	365.1 mm
Weight (without stand)	4600 g
