LG 32LS33A - RGB Connection

15
ENG
ENGLISH
MAKING CONNECTIONS
YourmonitorsupportsthePlug&Play*feature.
*Plug&Play:APCwillhaveabuilt-indriverfor
themonitor,noextrasoftwareisneeded.
NOTE

Connectthesignal
inputcableandtighten
itbyturningthescrews
clockwise.

Usethestandard
Macintoshadaptersince
anincompatibleadapter
isavailableinthemarket.
(Differentsignalingsystem)

Donotpressthescreenwithyourfingerfor
alongtimeasthismayresultintemporary
distortiononthescreen.

Avoiddisplayingafixedimageonthescreen
foralongperiodoftimetopreventimage
burn.Useascreensaverifpossible.
RGB Connection
TransmitsananalogvideosignalfromyourPCto
themonitor.ConnectthePCandthemonitorwith
the15-pinsignalcableasshownanfollowing
illustration.SelectRGBinput.Totransmitanaudio
signal,connectanoptionalaudiocable.

Applecomputersmayrequireanadapterto
connecttothismonitor.Callorvisittheirweb
siteformoreinformation.

ItisrecommendedyouuseanHDMI
connectionforthebestimagequality.

Useashieldedsignalinterfacecable,such
asD-sub15-pinsignalcableandDVI/HDMI
cable,withaferritecoretomaintainstandard
compliancefortheproduct.

Ifyouturnthemonitorsetonwhenthesetis
cold,thescreenmayflicker.Thisisnormal.

Somered,green,orbluespotsmayappear
onthescreen.Thisisnormal.

IfyouuseacablelongerthantheD-sub15-
pinsignalcableprovided,certainimages
mayappearblurry.
CAUTION
NOTE
Instructions for connecting to PC
PC/MAC
MacintoshAdapter
(notincluded)
(not
included)
Backoftheproduct.
