PRODUCT SPECIFICATION
LCD Screen Type TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Screen
Color Depth HDMI 8-bit color is supported.
DP (DisplayPort) 8-bit / 10-bit color is supported.
Pixel Pitch 0.22908 mm x 0.22908 mm
Resolution Max Resolution
Recommended Resolution
Video Signal Horizontal Frequency 30 kHz to 125 kHz
Vertical Frequency 56 Hz to 75 Hz
Synchronization Separate Sync.
Input Connector
H/P OUT, HDMI IN 1/2, DP (DisplayPort) IN, USB ( ) 1/2, USB-C ( )
Power Sources Power Rating 19 V 7.7 A
Power Consumption
(Typical)
Operating Mode: 70 W (Typical, USB excluded) (Outgoing condition)*
48 W (ENERGY STAR
®
standard)**
AC/DC Adapter DA-180C19 type, manufactured by APD
Output: 19 V 9.48 A
