Appendix38
Appendix
6
Specifications
General
Power requirements Refer to main label on the rear panel.
Power consumption 13 W
Dimensions (W x H x D) Approx. 360 x 40 x 190 mm
Net Weight (Approx.) 1.3 kg
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Outputs
VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
HDMI OUT (video/audio) 19 pin (Type A, HDMI
TM
Connector)
ANALOG AUDIO OUT 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
System
Laser Semiconductor laser
Wavelength 405 nm / 650 nm
Signal system Standard NTSC / PAL colour TV system
Frequency response 20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling)
Signal-to-noise ratio More than 90 dB (ANALOG OUT connectors only)
Harmonic distortion Less than 0.02%
Dynamic range More than 95 dB
Bus Power Supply (USB) DC 5 V
0
500 mA
y
Design and specications are subject to change without notice.
