Appendix70
Appendix
6
Specifications
General
Power requirements Refer to main label on the rear panel.
Power consumption 16 W
Dimensions (W x H x D) Approx. 430 mm x 37.5 mm x 203 mm (17” x 1.5” x 8”)
Net Weight (Approx.) 1.6 kg (3.5 lbs)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Outputs
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
DIGITAL AUDIO OUT (OPTICAL) 3 V (p-p), Optical jack x 1
System
Laser Semiconductor laser
Wavelength 405 nm / 650 nm
Signal system Standard NTSC colour TV system
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna)
Integrated IEEE 802.11n (5 GHz and 2.4 GHz bands) wireless
networking access, compatible with 802.11a/b/g Wi-Fi networks.
Bus Power Supply (USB) DC 5 V
0
500 mA
y
Design and specications are subject to change without notice.
