Function
35
Transmission
[k] [a] [ ] [Set ID] [ ] [Data] [Cr]
Data 0 : Power Off
1: Power On
Ack
[a] [ ] [Set ID] [ ] [OK] [Data] [x]
Data 0 : Power Off
1: Power On
Data 0 : Power Off
1: Power On
⇒ Gives information about power On/Off.
Transmission
[k] [a] [ ] [Set ID] [ ] [FF] [Cr]
Ack
[a] [ ] [Set ID] [ ] [OK] [Data] [x]
* As with other functions, if data is transmitted as ‘0xFF‘ in the above format,
the current status of each function is returned as a feedback
in Ack data.
⇒ Controls power On/Off of a set.
Transmission
[k] [c] [ ] [Set ID] [ ] [Data] [Cr]
Data 1 : Normal Screen (4:3) 2 : Wide Screen (16:9)
4: Zoom 6: Set By Program 9 : Just Scan
10-1f : Cinema Zoom 1-16
Ack
[c] [ ] [Set ID] [ ] [OK] [Data] [x]
Data 1 : Normal Screen (4:3) 2 : Wide Screen (16:9)
4: Zoom 6: Set By Program 9 : Just Scan
10-1f : Cinema Zoom 1-16
⇒ Adjusts screen size.
01.Power (Command:ka)
02. Aspect Ratio(Command:kc)
Transmission
[k] [d] [ ] [Set ID] [ ] [Data] [Cr]
Data 0: Screen Mute Off (video On)
1: Screen Mute On (video Off)
Ack
[d] [ ] [Set ID] [ ] [OK] [Data] [x]
Data 0: Screen Mute Off (video On)
1: Screen Mute On (video Off)
⇒ Controls screen Mute On/Off.
Transmission
[k] [g] [ ] [Set ID] [ ] [Data] [Cr]
Data Min : 0 - Max : 64
Ack
[g] [ ] [Set ID] [ ] [OK] [Data] [x]
Data Min : 0 - Max : 64
* Refer to the actual data structure 1.
⇒ Adjusts screen brightness.
03. Screen Mute (Command:kd)
04. Contrast (Command : kg)
Transmission
[k] [h] [ ] [Set ID] [ ] [Data] [Cr]
Data Min : 0H - Max : 64H
Ack
[h] [ ] [Set ID] [ ] [OK] [Data] [x]
Data Min : 0H - Max : 64H
* Refer to the actual data structure 1.
(* Transmitted in hexadecimal code)
⇒ Adjusts screen brightness.
05.Brightness(Command:kh)
Transmission
[k] [i] [ ] [Set ID] [ ] [Data] [Cr]
Data Min : 0 - Max : 64
(* Transmitted in hexadecimal code)
Ack
[i] [ ] [Set ID] [ ] [OK] [Data] [x]
Data Min : 0 - Max : 64
* Refer to the actual data structure 1.
⇒ Adjusts screen color. (Video / S-Video / Component)
06.Color (Command : ki)
