3-15
MAIN ELECTRICAL TROUBLESHOOTING GUIDE
3. RF/SERVO CIRCUIT
Replace IC(U201)
Laser off
Check the related circuit on
MT1389 RFL signal.
Check DMSO
related circuit on MT1389.
Check the RFL connection
between J401 and MT1389.
Check the cable connection
between spindle and main
PCBA.
YES
YES
YES
YES
NO
NO
NO
NO
NO
YES
YES
Disc ID
is correct?
Does
spindle rotate.
A
Put Disc in.
Proper RFL signal
on MT1389?
Proper
DMSO signal on
MT1389
21
23
Table of Contents
Section 1 Summary
3
Default Chapter
3
Table of Contents
3
Product Safety Servicing Guidelines for Video Products
4
Servicing Precautions
5
General Servicing Precautions
5
Insulation Checking Prodedure
5
Electrostatically Sensitive (Es) Devices
5
Specifications
6
Liquid Crystal Display
6
Exploded Views
8
Exploded Views
9
Cabinet and Main Frame Section
9
Packing Accessory Section
10
Section 3 Electrical
12
Lcd Part
13
Lcd Electrical Troubleshooting Guide
13
Block Diagram
14
Circuit Diagram
15
Printed Circuit Board Diagram
16
Main Part
18
Main Electrical Troubleshooting Guide
18
Power (DC-DC Converter Circuit)
18
Mpeg Circuit
21
Rf/Servo Circuit
22
Charging Circuit
25
Details and Waveforms on System Test and Debugging
26
SYSTEM 27Mhz CLOCK
26
Sdram Clock
26
Mt1389 Video Output Waveform
27
Audio Output from Audio Dac
27
Block Diagrams
28
Overall Block Diagram
28
Power Block Diagram
29
Servo Block Diagram
30
System Block Diagram
31
A/V Block Diagram
32
Circuit Diagrams
34
Mpeg Circuit Diagram
34
Memory Circuit Diagram
35
Opu & Motor Circuit Diagram
36
Av Circuit Diagram
37
Charge Circuit Diagram
38
Lcd I/F Circuit Diagram
39
Key Circuit Diagram
40
Circuit Voltage Chart
41
Printed Circuit Board Diagrams
43
Main P.C.board
43
Key P.C.board
45
