3-18
MAIN ELECTRICAL TROUBLESHOOTING GUIDE
4. CHARGING CIRCUIT
Is 8.4V of J601_Pin3 OK?
NO
YES
No turn on Red LED
Replace IC(U601).
NO
YES
Is IC(U601) OK?
Replace L601.
NO
YES
Is L601 OK?
Replace L602.
Replace IC(U603).
Is IC(U603) OK?
NO
NO
YES
Is L602 OK?
24
