LG DP450P Service Manual

3-43 3-44
MODE
PIN NO.
STOP PLAY
Q515
Emitter 5.06 4.96
Collector 0.5 0.48
Base 00
Q601
Emitter 12.26 12.25
Collector 12.26 12.26
Base 12.26 12.25
Q602
Emitter 12.26 12.25
Collector 00
Base 12.26 12.25
Q603
Emitter 00
Collector 12.26 12.25
Base 00
Q702
Emitter 00
Collector 00
Base 0 -1.92
Q1(5448)
Emitter 5.59 5.58
Collector 00
Base 00
Q2(5448)
Emitter 00
Collector 00
Base 0.70 0.70
Q1(5451)
Emitter 0.63 0.63
Collector 55
Base 1.33 1.33
Q2(5451)
Emitter 0.63 0.63
Collector 55
Base 1.32 1.32
Q3(5451)
Emitter 0.62 0.62
Collector 55
Base 1.32 1.32
CE201
+ 3.33 3.33
-00
CE202
+ 3.33 3.33
-00
CE203
+ 3.33 3.33
-00
CE204
+ 2.00 2.00
-00
CE205
+ 3.33 3.33
-00
MODE
PIN NO.
STOP PLAY
CE206
+ 1.41 1.40
-00
CE207
+ 3.33 3.32
-00
CE208
+ 1.87 1.87
-00
CE209
+ 3.33 3.33
-00
CE211
+ 3.33 3.32
-00
CE212
+ 3.26 3.26
-00
CE213
+ 3.33 3.33
-00
CE301
+ 3.33 3.33
-00
CE402
+ 5.07 4.98
-00
CE403
+ 5.07 5.00
-00
CE406
+ 5.06 5.00
-00
CE410
+ 3.39 3.38
-00
CE411
+ 9.80 9.71
-00
CE412
+ 5.06 5.04
-00
CE413
+ 9.80 9.71
-00
CE415
+ 3.37 3.36
-00
CE416
+ 5.15 4.99
-00
CE417
+ 3.34 3.33
- 3.34 3.33
CE418
MODE
PIN NO.
STOP PLAY
+ 3.34 3.33
- 3.34 3.33
CE501
+ 2.45 2.40
-00
CE502
+ 2.45 2.40
-00
CE503
+ 5.37 5.30
-00
CE504
+ 2.46 2.36
-00
CE505
+ 5.37 5.30
-00
CE506
+ 5.06 5.00
-00
CE507
+ 9.78 9.71
-00
CE508
+ 4.05 4.02
- 1.63 1.63
C509
+ 4.05 4.04
- 1.63 1.63
CE510
+ 1.65 1.50
-00
CE511
+ 5.55 5.50
-00
CE512
+ 5.55 5.50
-00
CE513
+ 2.48 2.39
-00
CE514
+ 1.89 1.80
-00
CE515
+ 2.47 2.40
-00
CE516
+ 4.45 4.41
-00
CE602
+ 10.13 10.08
-00
CE604
+ 8.40 8.40
MODE
PIN NO.
STOP PLAY
-00
CE605
+ 10.14 10.08
-00
CE606
+ 9.80 9.71
-00
CE607
+ 5.06 5.03
-00
CE610
+ 2.50 2.50
-00
CE701
+ 9.79 9.74
-00
