Chapter 2 SPECIFICATIONS
2 - 4
2.3.2 G4F-TC2A
The following gives the names and functions of each part of the G4F-TC2A.
]
2.3.3 G6F-TC2A
The following gives the names and functions of each part of the G6F-TC2A.
G6F
G6FG6F
G6F
-
--
-
TC2A
TC2ATC2A
TC2A
RJ
G6F-TC2A
INPUT
TYPE:K,J,
E,T,R,S,B
FG
RUN
+
-
CH1
+
-
CH0
+
-
CH2
+
-
CH3
①
②
No Contents
RUN LED
①
It displays the operating status of G6F-TC2A
z On : Normal Operation
z Flickering: Error occurred (For details, refer to
Troubleshooting Sec-
tion 9.1)
z Off : 5 VDC disconnection or
the G6F-TC2A module H/W error
Reference junction com-
pensation device
②
Reference junction compensation for type K, J, E, T, R or S.
No Contents
RUN LED
①
It displays the operating status of G4F-TC2A
z On : Normal Operation
z Flickering: Error occurred (For details, refer to
Troubleshooting Sec-
tion 9.1)
z Off : 5 VDC disconnection or
the G4F-TC2A module H/W error
Reference junction com-
pensation device
②
Reference junction compensation for type K, J, E, T, R or S.
①
②
