LG G3F-TC4A User Manual

Chapter 6. BUFFER MEMORY CONFIGURATION AND FUNCTIONS
6 - 3
6.1.2 G4F-TC2A / G6F-TC2A Buffer Memory
Address
(Decimal)
Function Description
Default Setting
Read /
Write
0 Channel enable/disable Specification Bit On(1): Enable, Bit Off(0) : Disable Disable R/W
1 Specifying the type of thermocouple for channel 0
2 Specifying the type of thermocouple for channel 1
3 Specifying the type of thermocouple for channel 2
4 Specifying the type of thermocouple for channel 3
Type K R/W
5 Temperature conversion value of the channel 0
6 Digital conversion value of the channel 0
7 Error code of the channel 0
8 Temperature conversion value of the channel 1
9 Digital conversion value of the channel 1
10 Error code of the channel 1
11 Temperature conversion value of the channel 2
12 Digital conversion value of the channel 2
13 Error code of the channel 2
14 Temperature conversion value of the channel 3
15 Digital conversion value of the channel 3
16 Error code of the channel 3
•
Temperature conversion value
: 10 times of a real temperature is displayed.
•
Digital conversion value
▶
If a temperature conversion value is converted into a
value within 0 to 16000, that value is a digital
conversion value.
▶
It can be used as a process value of the PID control
module.
▶
Expression
Digital conversion value = (16000/ measuring
temperature range)
×
(temperature conversion value – minimum
measuring temperature)
•
Error code
16 : Disconnection detection error
17 : Upper or lower overflow
18 : Reference junction compensation device
error

Read
Only
17 SET data
Bit On(1) : New setting values are set for the contents o
f address 0 to 4.
Bit Off(0) : The existing values of address 0 to 4 remains.
No
setting
R/W
18 Run channel information Bit On(1) : Running, Bit Off(0) : Stop

Read
only
19 Setting error information
Bit On(1) : if other value than 0 to 6 is set for specifying
the type of thermocouples in the address
1 to 4.
Bit Off(0) : If 0 to 6 is set for specifying the type of
thermocouples in the address 1 to 4.

Read
only
Input
specification
No.
Sensor type
Temperature
range
0 K
-200.0 to 1200.0
°
C
1 J
-200.0 to 800.0
°
C
2 E
-150.0 to 600.0
°
C
3 T
-200.0 to 400.0
°
C
4 B
400.0 to 1800.0
°
C
5 R
0.0 to 1750.0
°
C
6 S
0.0 to 1750.0
°
C
If a value outside the defined range is set, the
bit of address 19 that corresponds to the
channel turns on and the thermocouple type
will be set to type K.
