LG HB620 Service Manual

- 182 -
11. EXPLODED VIEW & REPLACEMENT PART LIST
LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
Level
Location
No.
Description Part Number Spec Color
Remark
5 MBIB00 BUSHING,HINGE MBIB0006601 CASTING, Zn Alloy, , , , , Without Color 42
5 MBJL00 BUTTON,SIDE MBJL0055101 COMPLEX, (empty), , , , , Red 41
5 MBJL01 BUTTON,SIDE MBJL0055001 COMPLEX, (empty), , , , , Red 48
5 MCCC00 CAP,EARPHONE JACK MCCC0053501 COMPLEX, (empty), , , , , Red 46
5MCJK00 COVER,FRONT MCJK0085501 MOLD, PC LUPOY SC-1004ML, , , , , Red 44
5MGAD00 GASKET,SHIELD FORM MGAD0159501 COMPLEX, (empty), , , , , Without Color
5MICC00 INSERT,FRONT(UPPER) MICC0010401 CUTTING, NS, , , , ,
WHITE
SILVER
5MICC01 INSERT,FRONT(UPPER) MICC0010001 D2.2 L2.0 KURL 45 Gold
5 MPBH00 PAD,MIKE MPBH0036701 COMPLEX, (empty), , , , , Without Color 47
5 MPFD00 PLATE,GROUND MPFD0004901 PRESS, STS, , , , , Without Color 45
5 MSGB00 STOPPER,HINGE MSGB0026201 COMPLEX, (empty), , , , , Red 29
5 MSGC00 STOPPER,FOLDER MSGC0002601 MOLD, Urethane Rubber S190A, , , , , Red 20, 43
5 MTAB00 TAPE,PROTECTION MTAB0221601 COMPLEX, (empty), , , , , Without Color 49
5 MTAB01 TAPE,PROTECTION MTAB0221501 COMPLEX, (empty), , , , , Without Color 40
4AWAB00 WINDOW ASSY,LCD AWAB0032501 MAIN Without Color
5 MTAD00 TAPE,WINDOW MTAD0084101 COMPLEX, (empty), , , , , Without Color 28
5MWAC00 WINDOW,LCD MWAC0095601 CUTTING, PMMA MR 200, , , , , Without Color 29
4GMEY00 SCREW MACHINE,BIND GMEY0011201 1.4 mm,3 mm,MSWR3(BK) ,N ,+ ,NYLOK Without Color
4 MCCH01 CAP,SCREW MCCH0124601 CUTTING, PMMA MR 200, , , , , Without Color 38
4 MCCH02 CAP,SCREW MCCH0124701 CUTTING, PMMA MR 200, , , , , Without Color 37
4 MCCH03 CAP,SCREW MCCH0124801 MOLD, PC LUPOY SC-1004ML, , , , , Red 36
5 MTAZ00 TAPE MTAZ0210101 COMPLEX, (empty), , , , , Without Color 32
4 MCCH04 CAP,SCREW MCCH0124901 MOLD, PC LUPOY SC-1004ML, , , , , Red 35
5 MTAZ00 TAPE MTAZ0210201 COMPLEX, (empty), , , , , Without Color 31
4MLAZ00 LABEL MLAZ0038303 PRINTING, (empty), , , , , White
4 MPBF00 PAD,FLEXIBLE PCB MPBF0034101 COMPLEX, (empty), , , , , Without Color
4 MPBQ00 PAD,LCD(SUB) MPBQ0037201 COMPLEX, (empty), , , , , Without Color
4 MSGB00 STOPPER,HINGE MSGB0026101 MOLD, PC LUPOY SC-1004A, , , , , Without Color
4 MTAB00 TAPE,PROTECTION MTAB0235701 COMPLEX, (empty), , , , , Without Color
4 MTAB01 TAPE,PROTECTION MTAB0235801 COMPLEX, (empty), , , , , Without Color
6 MTAC00 TAPE,SHIELD MTAC0074001 COMPLEX, (empty), , , , , Without Color
4 MCCZ00 CAP MCCZ0027901 MOLD, PC LUPOY SC-1004A, , , , , Without Color 56
4MCJN00 COVER,REAR MCJN0082501 MOLD, PC LUPOY SC-1004A, , , , , Black 60
4MICC00 INSERT,FRONT(UPPER) MICC0010001 D2.2 L2.0 KURL 45 Gold
4MLAB00 LABEL,A/S MLAB0001102 C2000 USASV DIA 4.0 White
4 MPBZ00 PAD MPBZ0201201 COMPLEX, (empty), , , , , Without Color 58
4 MPBZ01 PAD MPBZ0204801 COMPLEX, (empty), , , , ,
Black
