11. EXPLODED VIEW & REPLACEMENT PART LIST
- 181 -
11.2 Replacement Parts
<Mechanic component>
Note: This Chapter is used for reference, Part order
is ordered by SBOM standard on GCSC
Level
Location
No.
Description Part Number Spec Color Remark
2 AAAY00 ADDITION AAAY0310202 Black
2 APEY00 PHONE APEY0561101 Black
3 ACGG00 COVER ASSY,FOLDER ACGG0089501 Without Color
4 ABGF00 BUTTON ASSY,MAIN ABGF0002501 Without Color 50
4 ABGG00 BUTTON ASSY,SUB ABGG0002401 Without Color 18
4 ACGH00
COVER
ASSY,FOLDER(LOWER)
ACGH0052701 Without Color #3
5MCJH00 COVER,FOLDER(LOWER) MCJH0042601 CASTING, Al Alloy, , , , , Red 25
5MFBC00 FILTER,SPEAKER MFBC0038401 COMPLEX, (empty), , , , , Without Color 26
5MHFD00 HINGE,FOLDER MHFD0015901 COMPLEX, (empty), , , , , Without Color 27
5 MMAA00 MAGNET,SWITCH MMAA0000301 23
5 MPBN00 PAD,SPEAKER MPBN0053601 COMPLEX, (empty), , , , , Without Color 21
5MTAA00 TAPE,DECO MTAA0163801 COMPLEX, (empty), , , , , Without Color
5MTAF00 TAPE,MOTOR MTAF0017001 COMPLEX, (empty), , , , , Without Color 22
5MTAK00 TAPE,CAMERA MTAK0009401 COMPLEX, (empty), , , , , Without Color 24
4 ACGJ00
COVER
ASSY,FOLDER(UPPER)
ACGJ0069601 Without Color
5MCJJ00 COVER,FOLDER(UPPER) MCJJ0052201 MOLD, PC LUPOY SC-1004A, , , , , Black 3
5MDAE00 DECO,FOLDER(UPPER) MDAE0042301 PRESS, Al, 0.5, , , , Black 2
5MGAD00 GASKET,SHIELD FORM MGAD0167701 COMPLEX, (empty), , , , , Without Color
5MICZ00 INSERT MICZ0019901 Without Color 11, 30
5 MPBG00 PAD,LCD MPBG0074501 COMPLEX, (empty), , , , , Without Color 10
5 MPBG01 PAD,LCD MPBG0080601 COMPLEX, (empty), , , , , Without Color 7
5 MPBJ00 PAD,MOTOR MPBJ0051801 COMPLEX, (empty), , , , , Without Color
5 MPBN00 PAD,SPEAKER MPBN0058201 COMPLEX, (empty), , , , , Without Color
5 MPBT00 PAD,CAMERA MPBT0055301 COMPLEX, (empty), , , , , Without Color
5 MPBT01 PAD,CAMERA MPBT0055401 COMPLEX, (empty), , , , , Without Color 9
5 MPBU00 PAD,CONNECTOR MPBU0022401 COMPLEX, (empty), , , , , Without Color 5
5 MPBU01 PAD,CONNECTOR MPBU0022501 COMPLEX, (empty), , , , , Without Color 4
5MTAA00 TAPE,DECO MTAA0155401 COMPLEX, (empty), , , , , Without Color
5MTAB00 TAPE,PROTECTION MTAB0235901 COMPLEX, (empty), , , , , Without Color 1
5MTAE00 TAPE,WINDOW(SUB) MTAE0034001 COMPLEX, (empty), , , , , Without Color
5MWAF00 WINDOW,LCD(SUB) MWAF0040101 CUTTING, PMMA MR 200, , , , , Without Color
4 ACGK00 COVER ASSY,FRONT ACGK0107601 Without Color
#4
