- 72 -
3. TECHNICAL BRIEF
3.11 Feature List
3.11.1 USB Interface
* The MSM6280 device integrates a universal serial bus (USB) controller that supports both
unidirectional and bidirectional transceiver interfaces characteristics:
■ Compliant with both the USB 2.0 Specification and the OTG Supplement
■ Complies with 3-wire USB support only
■ USB Transceiver integrated in PM6650-3P power management device
■ Either low-speed (1.5Mbps) or full-speed (12Mbps) as a host
■ In peripheral mode, PM6650-3P supports charging from VBUS
■ MSM6280 with PM6650-3P also supports analog car kit mode (CEA-936-A)
LGE Internal Use Only
Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
