LG HB620 Service Manual

LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
2. PERFORMANCE
- 9 -
2.3 Radio Performance
2.3.1 Transmitter - GSM Mode
* In case of DCS : [A] -> 1710, [B] -> 1785* In case of PCS : [A] -> 1850, [B] -> 1910
No Item GSM850/900 DCS & PCS
1 Conducted MS allocated 100k~1GHz -39dBm 9k ~ 1GHz -39dBm
Spurious Channel 1G~[A]MHz -33dBm
Emission 1G~12.75GHz -33dBm [A]M~[B]MHz -39dBm
[B]M~12.75GHz -33dBm
Idle Mode 100k~880MHz -60dBm 100k~880MHz -60dBm
880M~915MHz -62dBm 880M~915MHz -62dBm
915M~1GHz -60dBm 915M~1GHz -60dBm
1G~[A]MHz -50dBm 1G~[A]MHz -50dBm
[A]M~[B]MHz -56dBm [A]M~[B]MHz -56dBm
[B]M~12.5GHz -50dBm [B]M~12.5GHz -50dBm
2 Radiated MS allocated 30M ~ 1GHz -36dBm 30M~1GHz 36dBm
Spurious Channel 1G~[A]MHz -30dBm
Emission 1G ~ 4GHz -30dBm [A]M~[B]MHz -36dBm
[B]M~4GHz -30dBm
Idle Mode 30M ~ 880MHz -57dBm 30M~880MHz -57dBm
880M ~ 915MHz -59dBm 880M~915MHz -59dBm
915M~1GHz -57dBm 915M~1GHz -57dBm
1G~[A]MHz -47dBm 1G~[A]MHz -47dBm
[A]M~[B]MHz -53dBm [A]M~[B]MHz -53dBm
[B]M~4GHz -47dBm [B]M~4GHz -47dBm
