3. TECHNICAL BRIEF
- 45 -
3.7 Subsystem(MSM6280)
3.7.1 ARM Microprocessor Subsystem
The MSM6280 device uses an embedded ARM926EJ-S microprocessor. This microprocessor,
through the system software, controls most of the functionality for the MSM, including control of the
external peripherals such as the keypad, LCD, SDRAM, and NAND-Flash devices. Through a
QUALCOMM proprietary serial bus interface (SBI) the ARM926EJ-S configures and controls the
functionality of the RTR6275 and PM6650 devices.
3.7.2 WCDMA R99 features
The MSM6280 device supports release 99 June 2004 of the W-CDMA FDD standard, including the
following features:
■ All modes and data rates for W-CDMA frequency division duplex (FDD), with the following
restrictions:
■ The downlink supports the following specifications:
- Up to four physical channels, including the broadcast channel (BCH), if present
- Up to three dedicated physical channels (DPCHs)
- Spreading factor (SF) range support from 4 to 256
- The following transmit diversity modes are supported:
Space time transmit diversity (STTD)
Time-switched transmit diversity (TSTD)
Closed-loop feedback transmit diversity (CLTD)
■ The uplink supports the following specifications:
■ The uplink provides the following UE support:
- One physical channel, eight TrCH, and 16 TrBks starting at any frame boundary
- A maximum data rate of 384 kbps
■ SMS (CS and PS)
■ Full SF range support from 4 to 256
■ PS data rate - 384 kbps DL / 384 kbps UL
■ CS data rate - 64 kbps DL / 64 kbps UL
■ AMR (all rates)
