2. PERFORMANCE
- 7 -
2.1 System Overview
2. PERFORMANCE
Item Specification
Shape GSM900/1800/1900 and WCDMA Folder Handset
Size 88.5 x 54.9 x17.9 mm
Weight 110 g (with 1000mAh Battery)
Power 4.0V normal, 1000 mAh(Li-ion) inner-pack
Talk Time Over 180 min (WCDMA, Tx=12 dBm, Voice)
(with 1000mAh) Over 180 min (GSM, Tx=Max, Voice)
Standby Time Over 250 Hrs (WCDMA, DRX=1.28)
(with 1000mAh) Over 320 Hrs (GSM, Paging period=5)
Antenna Internal type
LCD Main 320 x 240 pixel (TFT) / sub 34 x 96 pixel (TFT)
LCD Backlight White LED Back Light (2way ; main/sub common)
Camera 2.0 Mega (CMOS) / VGA (CMOS).
Vibrator Yes
LED Indicator No
MIC Yes
Receiver Yes
Earphone Jack Yes (18 pin)
Connectivity Bluetooth, USB
Volume Key Push Type (+, -)
External Memory Trans-Flash
I/O Connect 18 Pin
