LG HB620 Service Manual

- 184 -
11. EXPLODED VIEW & REPLACEMENT PART LIST
LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
Level
Location
No.
Description Part Number Spec Color Remark
1 IMT,FOLDER TIFF0016201
4 SACY00 PCB ASSY,FLEXIBLE SACY0075303 12
5 SACB00
PCB
ASSY,FLEXIBLE,INSERT
SACB0047101
5 SACE00 PCB ASSY,FLEXIBLE,SMT SACE0069901
6 SACC00
PCB ASSY,FLEXIBLE,SMT
BOTTOM
SACC0046501
7C111 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7 C952 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7 CN101
CONNECTOR,BOARD TO
BOARD
ENBY0031501 70 PIN,0.4 mm,ETC , ,H=1.5, Socket
7 CN102
CONNECTOR,BOARD TO
BOARD
ENBY0018501 10 PIN,.4 mm,STRAIGHT , ,H=0.9,HEADER
7 CN103
CONNECTOR,BOARD TO
BOARD
ENBY0020201 40 PIN,0.4 mm,ETC , ,H=0.9, Header
6 SACD00
PCB ASSY,FLEXIBLE,SMT
TOP
SACD0059401
7 C101 CAP,TANTAL,CHIP ECTH0004808
4.7 uF,10V ,M ,STD ,1608 ,R/TP ,; , ,[empty] ,[empty] , ,-
55TO+125C , ,[empty] ,[empty] ,[empty] ,[empty]
7 C102 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7 C103 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7 C104 CAP,TANTAL,CHIP ECTH0004807
10 uF,10V ,M ,STD ,1608 ,R/TP ,; , ,[empty] ,[empty] , ,-
55TO+125C , ,[empty] ,[empty] ,[empty] ,[empty]
7 C105 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP
7 C106 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7 C107 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7 C306 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7 C307 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7 C409 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C951 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C954 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP
7 C955 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP
7 C956 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP
7 CN104
CONNECTOR,BOARD TO
BOARD
ENBY0020401 24 PIN,0.4 mm,ETC , ,H=0.9, Socket
7 CN105
CONNECTOR,BOARD TO
BOARD
ENBY0019501 20 PIN,.4 mm,ETC , ,H=1.5, Socket
7 D402 DIODE,TVS EDTY0008610
SOD-523 ,5 V,250 W,R/TP ,PB-FREE
11.2 Replacement Parts
<Main component>
Note: This Chapter is used for reference, Part order
is ordered by SBOM standard on GCSC
