LG HB620 Service Manual

- 185 -
11. EXPLODED VIEW & REPLACEMENT PART LIST
LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
Level
Location
No.
Description Part Number Spec Color
Remark
7 D403 DIODE,SWITCHING EDSY0011901
EMD2 ,30 V,1 A,R/TP ,VF=1.5V(IF=200mA) ,
IR=30uA(VR=10V)
7FB1 FILTER,BEAD,CHIP SFBH0000909 60 ohm,1005 ,
7 R101 RES,CHIP ERHY0000280 100K ohm,1/16W,J,1005,R/TP
7 R102 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R103 RES,CHIP ERHY0000124 7.5K ohm,1/16W,F,1005,R/TP
7 R940 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
7 U101 IC EUSY0295501 TQFN , PIN,R/TP ,6 BLU+2 LDO+1 Flash LED Drv, 4*4
7 U102 IC EUSY0346101
WDFN ,8 PIN,R/TP ,2X2 1.5V/2.8V 300mA/300mA Dual
LDO ,; ,IC,LDO Voltage Regulator
7 VA101 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7 VA102 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7 VA103 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7 VA104 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7 VA105 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7 VA109 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7 VA110 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 SPCY00 PCB,FLEXIBLE SPCY0122101 POLYI , mm,MULTI-4 , ,; , , , , , , , , ,
4 SAEY00 PCB ASSY,KEYPAD SAEY0061401 17
5 SAEB00
PCB
ASSY,KEYPAD,INSERT
SAEB0025501
6ADCA00 DOME ASSY,METAL ADCA0078501 HOT KEY Without Color
5 SAEE00 PCB ASSY,KEYPAD,SMT SAEE0028601
6 SAEC00
PCB ASSY,KEYPAD,SMT
BOTTOM
SAEC0027101
7CN102
CONNECTOR,BOARD TO
BOARD
ENBY0018601 10 PIN,.4 mm,STRAIGHT , ,H=0.9, SOCKET
7 VA1 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7 VA2 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7 VA3 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7 VA4 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 SAED00
PCB ASSY,KEYPAD,SMT
TOP
SAED0026601
6 SPEY PCB,KEYPAD SPEY0053001 FR-4 ,0.5 mm,DOUBLE , ,; , , , , , , , , ,
4 SJMY00 VIBRATOR,MOTOR SJMY0007105 3 V,0.08 A,10*2.7 ,12mm ,; ,3V , , ,12000 RPM , , , , 15
4SUSY00 SPEAKER SUSY0027502 ASSY ,8 ohm,90 dB,1812 mm,15mm ,; , , , , , , ,WIRE 14
4 SVCY00 CAMERA SVCY0014001 CMOS ,VGA ,5.5x11.4x3.2t, Magna 1/7.4" 13
4 SVCY01 CAMERA SVCY0015801 CMOS ,MEGA ,2M SS LSI 1/4" Sensor( 8" Wafer)
4 SVLM00 LCD MODULE SVLM0028301
MAIN ,2.0" 320*240 + 1.17" 96*96 ,42.4*46*3.0t ,262k
,TFT ,TM ,R61513 / NT39107 ,
16
