11. EXPLODED VIEW & REPLACEMENT PART LIST
- 186 -
Level
Location
No.
Description Part Number Spec Color
Remark
3 ACGM00 COVER ASSY,REAR ACGM0109301 Without Color #5
4 ENZY00 CONNECTOR,ETC ENZY0019901 3 PIN,3 mm,STRAIGHT , ,
4GMEY00 SCREW MACHINE,BIND GMEY0011201 1.4 mm,3 mm,MSWR3(BK) ,N ,+ ,NYLOK Without Color
4SNGF00 ANTENNA,GSM,FIXED SNGF0034302
3.0 ,-2.0 dBd, ,EGSM+DCS+PCS+W-BAND I, INTERNAL
,; ,QUAD ,-2.0 ,50 ,3.0
59
4SNGR00
ANTENNA,GSM,RETRACTA
BLE
SNGR0000701 4.5 ,4.5 ,-7 dBd,-7 dBd,RED ,DVB-H, HINGE 57
3GMEY00 SCREW MACHINE,BIND GMEY0011201 1.4 mm,3 mm,MSWR3(BK) ,N ,+ ,NYLOK Without Color
3 SAFY00 PCB ASSY,MAIN SAFY0257701 Black
4 SAFB00 PCB ASSY,MAIN,INSERT SAFB0085801
5ADCA00 DOME ASSY,METAL ADCA0078601 Without Color 51
5 SPKY00 PCB,SIDEKEY SPKY0054701 POLYI , mm,DOUBLE , ,; , , , , , , , , ,
5 SPKY01 PCB,SIDEKEY SPKY0054801 POLYI , mm,DOUBLE , ,; , , , , , , , , ,
4 SAFF00 PCB ASSY,MAIN,SMT SAFF0174001
5 SAFC01
PCB ASSY,MAIN,SMT
BOTTOM
SAFC0108001
6ANT701ANTENNA,GSM,FIXED SNGF0026001
3.0 ,-2.0 dBd, ,Bluetooth, SMD, 8.0*2.0*1.2 ,; ,SINGLE ,-
2.0 ,50 ,3.0
6C102 INDUCTOR,CHIP ELCH0004707 1.5 nH,S ,1005 ,R/TP ,
6C103 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C104 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6C105 CAP,CERAMIC,CHIP ECCH0000127 82 pF,50V,J,NP0,TC,1005,R/TP
6C106 INDUCTOR,CHIP ELCH0001403 1 nH,S ,1005 ,R/TP ,PBFREE
6C107 CAP,CERAMIC,CHIP ECCH0000107 6 pF,50V,D,NP0,TC,1005,R/TP
6C108 CAP,CHIP,MAKER ECZH0000806 5 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP
6C109 CAP,CERAMIC,CHIP ECCH0000149 3.3 nF,50V,K,X7R,HD,1005,R/TP
6C110 CAP,CERAMIC,CHIP ECCH0000127 82 pF,50V,J,NP0,TC,1005,R/TP
6C111 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C112 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C113 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C114 CAP,CHIP,MAKER ECZH0000816 12 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C115 CAP,CERAMIC,CHIP ECCH0000393
22000000 pF,6.3V ,M ,X5R ,HD ,2012 ,R/TP , , ,[empty]
,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,1.25 mm
6C116 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
6C117 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6C118 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6C119 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
6C120 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6C121 CAP,CHIP,MAKER ECZH0000830
33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
