11. EXPLODED VIEW & REPLACEMENT PART LIST
- 187 -
Level
Location
No.
Description Part Number Spec Color
Remark
6 C122 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6 C123 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
6 C124 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6 C125 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
6 C126 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP
6 C127 CAP,TANTAL,CHIP ECTH0005501
33 uF,10V ,M ,L_ESR ,2012 ,R/TP ,; , ,[empty] ,[empty] ,
,-55TO+125C , ,[empty] ,[empty] ,[empty] ,[empty]
6 C128 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
6 C129 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6C130 CAP,CERAMIC,CHIP ECCH0000393
22000000 pF,6.3V ,M ,X5R ,HD ,2012 ,R/TP , , ,[empty]
,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,1.25 mm
6C131 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C132 CAP,CHIP,MAKER ECZH0000844 68 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C133 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
6C134 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
6C135 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP
6C136 CAP,CHIP,MAKER ECZH0000841 56 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C138 CAP,CHIP,MAKER ECZH0000841 56 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C139 CAP,CERAMIC,CHIP ECCH0000112 15 pF,50V,J,NP0,TC,1005,R/TP
6C140 CAP,CERAMIC,CHIP ECCH0000112 15 pF,50V,J,NP0,TC,1005,R/TP
6C142 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C143 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6C144 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
6C145 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP
6C146 INDUCTOR,CHIP ELCH0005020 1 nH,S ,1005 ,R/TP ,
6C147 INDUCTOR,CHIP ELCH0005020 1 nH,S ,1005 ,R/TP ,
6C148 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
6C149 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
6C150 CAP,CERAMIC,CHIP ECCH0000112 15 pF,50V,J,NP0,TC,1005,R/TP
6C152 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
6C153 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C154 INDUCTOR,CHIP ELCH0005020 1 nH,S ,1005 ,R/TP ,
6C155 INDUCTOR,CHIP ELCH0005020 1 nH,S ,1005 ,R/TP ,
6C156 CAP,TANTAL,CHIP ECTH0004807
10 uF,10V ,M ,STD ,1608 ,R/TP ,; , ,[empty] ,[empty] , ,-
55TO+125C , ,[empty] ,[empty] ,[empty] ,[empty]
6C157 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP
6C158 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C159 CAP,CHIP,MAKER ECZH0000830
33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
