11. EXPLODED VIEW & REPLACEMENT PART LIST
- 202 -
11.3 Accessory
Note: This Chapter is used for reference, Part order
is ordered by SBOM standard on GCSC
Level
Location
No.
Description Part Number Spec Color Remark
3 ADEY DATA KIT ADEY0010115 HB620 FOR ITALY HUTCHISON Without Color
4 MCHZ00 COMPACT DISK MCHZ0048301 COMPLEX, (empty), , , , ,
SILVER
SNOW
4 MEAY00 ENVELOPE MEAY0000401 PRINTING, (empty), , , , , Without Color
3MCJA00 COVER,BATTERY MCJA0060501 MOLD, PC LUPOY SC-1004A, , , , , Black 63
3 SBPL00 BATTERY PACK,LI-ION SBPL0091101
3.7 V,1000 mAh,1 CELL,PRISMATIC ,KU990(NYX)
BATT, Europe Label, Pb-Free ,; ,3.7 ,1000 ,0.2C
,PRISMATIC ,46x34x55 , ,BLACK ,Innerpack
,Europe(Reverse insert OK)
Black
3SGDY00 DATA CABLE SGDY0010904
; ,[empty] ,[empty] ,[empty] ,18 ,BLACK ,6.2mm Plug
Datacable ,[empty]
3SGEY00
EAR PHONE/EAR MIKE
SET
SGEY0003719
; ,RMS 20mW(0.56V,RMS) ,16 ohm +/- 2.4 ohm 1KHZ
,116dB +/- 3dB 1KHZ,3mW ,116dB 1KHZ ,96dB 100HZ
,[empty] ,BLACK ,18P MMI CONNECTOR
,Earphone,Stereo
3 SSAD00 ADAPTOR,AC-DC SSAD0024501
100-240V ,5060 Hz,5.1 V,.7 A,CE ,AC-DC ADAPTOR ,;
,85Vac~264Vac ,5.1V +0.15V, -0.2V ,700mA ,5060 ,
,WALL 2P ,I/O CONNECTOR ,
ADAPTOR,AC-DC SSAD0024502
100-240V ,5060 Hz,5.1 V,0.7 A,CE ,AC-DC ADAPTOR ,;
,5.1V +0.15V, -0.2V ,5.1V ,700mA ,5060 , ,WALL 2P ,I/O
CONNECTOR ,
ADAPTOR,AC-DC SSAD0024503
100-240V ,5060 Hz,5.1 V,.7 A,CE ,AC-DC ADAPTOR ,;
,85Vac~264Vac ,5.1V (+0.15V, -0.2V) ,700mA ,5060 ,
,WALL 2P ,I/O CONNECTOR ,
ADAPTOR,AC-DC SSAD0024504
100-240V ,5060 Hz,5.1 V,.7 A,CE ,AC-DC ADAPTOR ,;
,85Vac~264Vac ,5.1V(+0.15V, -0.2V) ,700mA ,5060 ,
,WALL 2P ,I/O CONNECTOR ,
