11. EXPLODED VIEW & REPLACEMENT PART LIST
LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
Level
Location
No.
Description Part Number Spec Color
Remark
6 R114 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6 R116 RES,CHIP,MAKER ERHZ0000294 5100 ohm,1/16W ,F ,1005 ,R/TP
6 R117 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W ,J ,1005 ,R/TP
6 R118 RES,CHIP,MAKER ERHZ0000264 3000 ohm,1/16W ,F ,1005 ,R/TP
6R120 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP
6R123 RES,CHIP ERHY0000147 56K ohm,1/16W,F,1005,R/TP
6R124 RES,CHIP,MAKER ERHZ0000244 22 Kohm,1/16W ,F ,1005 ,R/TP
6R125 RES,CHIP,MAKER ERHZ0000407 1000 Kohm,1/16W ,J ,1005 ,R/TP
6R126 RES,CHIP,MAKER ERHZ0000285 470 ohm,1/16W ,F ,1005 ,R/TP
6R188
PCB ASSY,MAIN,PAD
SHORT
SAFP0000501
6S101 CONN,SOCKET ENSY0013501
8 PIN,ETC ,PUSH-PUSH TYPE / RECTANGULAR ,1.1
mm,TRANS FLASH SOCKET / EXTERNAL MEMORY
CARD SOCKET
6SC1 CAN,SHIELD MCBA0027901 PRESS, STS, , , , , Without Color
6SW3 CONN,RF SWITCH ENWY0004401 ,SMD , dB,H=2.2
6 U103
TRANSFORMER,MATCHIN
G
STMY0024701
4 PIN,SMD ,Pb-free_DVB-H Balun ,; ,686 ,0.4 ,BPF ,SMD
,R/TP ,
6 U104 MODULE,ETC SMZY0017001 RF + Demod 1 chip ,; ,DMB
6 VA101 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA102 VARISTOR SEVY0007301 5 V,<0.5pF ,SMD ,
6X101 X-TAL EXXY0015502 30 MHz,50 PPM,12 pF,40 ohm,SMD ,3.2*2.5*0.7 ,
5 SAJD00 PCB ASSY,SUB,SMT TOP SAJD0026801
6 C101 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
6 C102 CAP,CHIP,MAKER ECZH0001420 1 uF,10V ,K ,X5R ,HD ,1608 ,R/TP
6 C103 CAP,CERAMIC,CHIP ECCH0007802 4.7 uF,10V ,M ,X5R ,TC ,1608 ,R/TP
6 C104 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6 C105 CAP,CERAMIC,CHIP ECCH0007802 4.7 uF,10V ,M ,X5R ,TC ,1608 ,R/TP
6 C108 CAP,CHIP,MAKER ECZH0001421 2.2 uF,6.3V ,K ,X5R ,HD ,1608 ,R/TP
6 CN101
CONNECTOR,BOARD TO
BOARD
ENBY0029501 40 PIN,0.4 mm,ETC , ,H=3.0, Socket
6L101 INDUCTOR,CHIP ELCH0005006 33 nH,J ,1005 ,R/TP ,
6L102 INDUCTOR,SMD,POWER ELCP0008004
4.7 uH,M ,1 ,R/TP , ,; , ,0.3NH , , , , , ,NON SHIELD
,2.5X2X1MM ,11MM ,R/TP
6R109 RES,CHIP ERHY0000140 36K ohm,1/16W,F,1005,R/TP
6 R115 RES,CHIP ERHY0000147 56K ohm,1/16W,F,1005,R/TP
6 U102 IC EUSY0264501 SC70JW-8 ,8 PIN,R/TP ,400mA, ADJ, DC/DC,PBFREE
6 U105 IC EUSY0356901
SON6 ,6 PIN,R/TP ,1.8V 300mA LDO ,; ,IC,LDO Voltage
Regulator
5 SPJY PCB,SUB SPJY0051101
FR-4 , mm,BUILD-UP 4 , ,; , , , , , , , , ,
