LG HB620 Service Manual

- 200 -
11. EXPLODED VIEW & REPLACEMENT PART LIST
LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
Level
Location
No.
Description Part Number Spec Color
Remark
6 C114 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6 C115 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6 C116 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6 C117 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6 C118 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6 C119 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
6C120 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
6C121 CAP,CERAMIC,CHIP ECCH0000110 10 pF,50V,D,NP0,TC,1005,R/TP
6C122 CAP,CERAMIC,CHIP ECCH0001002 180 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C123 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
6C124 CAP,CHIP,MAKER ECZH0000824 20 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C125 CAP,CHIP,MAKER ECZH0000824 20 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C130 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6C131 CAP,CHIP,MAKER ECZH0000827 2.4 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP
6C198 CAP,CERAMIC,CHIP ECCH0004905 0.82 pF,6.3V ,Z ,NP0 ,HD ,1005 ,R/TP
6C199 CAP,CERAMIC,CHIP ECCH0000196 0.75 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP
6 CN102 CONNECTOR,ETC ENZY0018801 PIN, mm,ETC , ,RCS=1.35
6FL101 FILTER,SAW SFSY0037401
897.5 MHz,1.4*1.1*0.6 ,SMD ,470M~750M 2.3, ~798M
1.9, ~862M 6.5, 5pin, U, 50, DVB-H BPF ,; ,897.5
,1.4*1.1*0.6 ,SMD ,R/TP
6L103 INDUCTOR,CHIP ELCH0012505 22 nH,G ,1005 ,R/TP ,Chip coil
6L106 INDUCTOR,CHIP ELCH0001031 15 nH,J ,1005 ,R/TP ,PBFREE
6L108 INDUCTOR,CHIP ELCH0012505 22 nH,G ,1005 ,R/TP ,Chip coil
6L110 INDUCTOR,CHIP ELCH0010502 33 nH,J ,1005 ,R/TP ,Laser Cutting Type
6L113 INDUCTOR,CHIP ELCH0012502 10 nH,G ,1005 ,R/TP ,chip coil
6L114 INDUCTOR,CHIP ELCH0012502 10 nH,G ,1005 ,R/TP ,chip coil
6L121 INDUCTOR,CHIP ELCH0010502 33 nH,J ,1005 ,R/TP ,Laser Cutting Type
6L198 INDUCTOR,CHIP ELCH0012510 15 nH,G ,1005 ,R/TP ,chip coil
6L199 INDUCTOR,CHIP ELCH0012510 15 nH,G ,1005 ,R/TP ,chip coil
6 R101 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6 R102 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6 R103 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6 R104 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6 R105 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6R110 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
6R111 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6R112 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6R113 CAP,CHIP,MAKER ECZH0000830
33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
