11. EXPLODED VIEW & REPLACEMENT PART LIST
- 199 -
Level
Location
No.
Description Part Number Spec Color
Remark
6 R903 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R907 RES,CHIP,MAKER ERHZ0000404 1 Kohm,1/16W ,J ,1005 ,R/TP
6 R908 RES,CHIP,MAKER ERHZ0000404 1 Kohm,1/16W ,J ,1005 ,R/TP
6 SPFY00 PCB,MAIN SPFY0169401 FR-4 ,0.8 mm,STAGGERED-8 , ,; , , , , , , , , ,
6U304 IC EUSY0340301
uMLP ,10 PIN,R/TP ,typ Rdson 0.4ohm, 1.4X1.8 ,;
,IC,Analog Switch
6 U703 IC EUSY0129503 2x2 mm MLPD ,3 PIN,R/TP ,Hall Effect Switch, Pb Free
6 VA401 VARISTOR SEVY0003801 18 V, ,SMD ,
6 VA501 VARISTOR SEVY0000701 14 V, ,SMD ,120pF, 1005
6 VA502 CAP,CERAMIC,CHIP ECCH0000123 51 pF,50V,J,NP0,TC,1005,R/TP
6 VA503 CAP,CERAMIC,CHIP ECCH0000123 51 pF,50V,J,NP0,TC,1005,R/TP
6 VA504 CAP,CERAMIC,CHIP ECCH0000123 51 pF,50V,J,NP0,TC,1005,R/TP
6 VA505 CAP,CERAMIC,CHIP ECCH0000123 51 pF,50V,J,NP0,TC,1005,R/TP
6 VA506 CAP,CERAMIC,CHIP ECCH0000123 51 pF,50V,J,NP0,TC,1005,R/TP
6 VA508 CAP,CERAMIC,CHIP ECCH0000123 51 pF,50V,J,NP0,TC,1005,R/TP
6 VA509 CAP,CERAMIC,CHIP ECCH0000123 51 pF,50V,J,NP0,TC,1005,R/TP
6 VA510 CAP,CERAMIC,CHIP ECCH0000123 51 pF,50V,J,NP0,TC,1005,R/TP
6 VA511 CAP,CERAMIC,CHIP ECCH0000123 51 pF,50V,J,NP0,TC,1005,R/TP
6 VA512 CAP,CERAMIC,CHIP ECCH0000123 51 pF,50V,J,NP0,TC,1005,R/TP
5WSYY00 SOFTWARE WSYY0816101 DZ_HB620AT-00-V10a-H3G-IT-MAY-02-2008+0
3 SAJY00 PCB ASSY,SUB SAJY0031801 55
4 SAJB00 PCB ASSY,SUB,INSERT SAJB0015901
5MCBA00 CAN,SHIELD MCBA0032801 PRESS, STS, , , , , Without Color
5MFEA00 FRAME,SHIELD MFEA0020101 CASTING, Al Alloy, , , , , Without Color 54
5MGAD00 GASKET,SHIELD FORM MGAD0164801 COMPLEX, (empty), , , , , Without Color
5 MPBZ00 PAD MPBZ0211001 COMPLEX, (empty), , , , , Without Color
4 SAJE00 PCB ASSY,SUB,SMT SAJE0025301
5 SAJC00
PCB ASSY,SUB,SMT
BOTTOM
SAJC0024201
6 BAT101 BATTERY,CELL,LITHIUM SBCL0001701
2 V,0.5 mAh,CYLINDER ,Reflow type BB, Max T 1.67, phi
4.8, Pb-Free
6C106 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C107 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6C109 CAP,CERAMIC,CHIP ECCH0000113 18 pF,50V,J,NP0,TC,1005,R/TP
6C110 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6C111 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6C112 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6C113 CAP,CHIP,MAKER ECZH0003103
0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
