LG HB620 Service Manual

LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
11. EXPLODED VIEW & REPLACEMENT PART LIST
- 198 -
Level
Location
No.
Description Part Number Spec Color
Remark
6 LD505 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD506 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD507 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD508 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD509 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD510 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD511 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD512 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD513 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD514 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD515 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD516 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 R313 RES,CHIP,MAKER ERHZ0000240 20 ohm,1/16W ,F ,1005 ,R/TP
6 R314 RES,CHIP,MAKER ERHZ0000240 20 ohm,1/16W ,F ,1005 ,R/TP
6 R315 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
6 R411 RES,CHIP,MAKER ERHZ0000204 100 Kohm,1/16W ,F ,1005 ,R/TP
6R504 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
6R505 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
6R506 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
6R507 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
6 R511 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R512 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R513 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R514 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R515 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R516 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R517 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R518 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R519 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R520 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R707 RES,CHIP,MAKER ERHZ0000500 62 ohm,1/16W ,J ,1005 ,R/TP
6 R708 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6R838 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6R839 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R900 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R901 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R902 RES,CHIP,MAKER ERHZ0000483
47 ohm,1/16W ,J ,1005 ,R/TP
