LG HB620 Service Manual

LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
11. EXPLODED VIEW & REPLACEMENT PART LIST
- 197 -
Level
Location
No.
Description Part Number Spec Color
Remark
6 VA507 CAP,CERAMIC,CHIP ECCH0000123 51 pF,50V,J,NP0,TC,1005,R/TP
6 VA701 DIODE,TVS EDTY0009401
VMN2 ,5 V,10 W,R/TP ,1.0*0.6*0.4 ,; , ,7.82V , , ,100mW
,[empty] ,[empty] ,2P ,1
6 VA702 DIODE,TVS EDTY0009401
VMN2 ,5 V,10 W,R/TP ,1.0*0.6*0.4 ,; , ,7.82V , , ,100mW
,[empty] ,[empty] ,2P ,1
6 VA703 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA704 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA705 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA706 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA707 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA708 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA709 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA710 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA711 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA712 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA713 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA714 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA715 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6X101 VCTCXO EXSK0007802
19.2 MHz,1.5 PPM,10 pF,SMD ,3.3*2.5*1.0 , ,; , ,2PPM
,2.8V , , , , ,SMD ,P/TP
6X201 RESONATOR EXRY0002401
48 MHz,.5 %,14 pF,SMD ,2.0*1.2*0.65 ,Outgoing
Tolerance 0.2%, 0.05% at -40'C ~ +85C, Built-In Cap
6X401 X-TAL EXXY0024301
32.768 KHz,20 PPM,12.5 pF,70 Kohm,SMD ,3.2*1.5*0.9
,-40'C ~ +85'C, C0 1.05pF, C1 fF ,; ,32.768 ,20PPM ,12.5
, , ,SMD ,R/TP
6X801 X-TAL EXXY0017801
12 MHz,50 PPM,8 pF,80 ohm,SMD ,3.2*2.5*0.75 ,20ppm
at 25'C, 30ppm at -30'C ~ +85'C
6ZD1 DIODE,TVS EDTY0009401
VMN2 ,5 V,10 W,R/TP ,1.0*0.6*0.4 ,; , ,7.82V , , ,100mW
,[empty] ,[empty] ,2P ,1
5 SAFD00 PCB ASSY,MAIN,SMT TOP SAFD0106501
6C334 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP
6 C710 CAP,CERAMIC,CHIP ECCH0000112 15 pF,50V,J,NP0,TC,1005,R/TP
6 C711 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
6FB302 FILTER,BEAD,CHIP SFBH0007103 75 ohm,1005 ,CHIP BEAD, 300mA
6FB303 FILTER,BEAD,CHIP SFBH0007103 75 ohm,1005 ,CHIP BEAD, 300mA
6FL501 FILTER,EMI/POWER SFEY0013201 SMD ,1608 ,EMI-ESD Filter, 4ch, 14V, 15pF, 100ohm
6FL505 FILTER,EMI/POWER SFEY0013201 SMD ,1608 ,EMI-ESD Filter, 4ch, 14V, 15pF, 100ohm
6LD501 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6LD502 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6LD503 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6LD504 DIODE,LED,CHIP EDLH0012501
Snow White ,1608 ,R/TP ,color concept
