LG HM031M User Manual

Air-to-Water Heat Pump _ 6
Part 3. Accessories
3. Domestic Hot Water Tank Kit(PHLTB)
3.1 Model
3.2 Part Description
Must be used for communication of Domestic Hot Water Tank and AWHP Unit.
* When connecting PHLTB, please refer to the manual supplied with.
< PHLTB >
Terminal
Block 3
Magnetic switch
contact
MCCB
Sensor (Thermister) – Th12
Water tank kit
Installation Manual
Multi harness (only AHBWXXXA0 model use)
1
2
3
4
2
3
4
1
